• IEEE Compliant Wireless LAN and Wired LAN
• Compliant with IEEE 802.11b/g/n/ac/ax 2.4GHz & 5GHz (Up to 1500Mbps) wireless technology
• Supports OFDMA, MU-MIMO, QAM-1024, BSS Coloring
• Advanced Networking Function for Specific Application: Supports Bandwidth Control (QoS) based on different local IP addresses
• Easy Installation and Management
• Web-based UI and Quick Setup Wizard for easy configuration
• Remote Management allows configuration from a remote site
• System status monitoring includes DHCP Client List and System Log
| Frequency Support | • FDD LTE: B1/3/5/7/8/20/28 • TDD 38,40,41 |
|
| Data Rate | • 2.4GHz & 5GHz up to 1500Mbps | |
| Standards | • 802.11b/g/n/ac/ax | |
| Wi-Fi Data Rate | • 2.4GHz (20/40MHz): up to 300 Mbps • 5GHz (20/40/80MHz): up to 1204 Mbps |
|
| Device Interfaces | • 1x Gigabit Ethernet WAN/LAN port • 3x Gigabit Ethernet LAN ports • 1x Reset/WPS button • 1 x Power jack • 2 x 5dBi external LTE antennas • 2 x 5dBi external WiFi antennas • 1 x Power switch • 1x LTE Interface • 1x Nano SIM card Slot |
|
| Wireless Encryption | • Wi-Fi Protected Setup (WPS) • WPA/WPA2/WPA3 wireless encryption • 64/128-bit WEP (Wired Equivalent Privacy) • Wireless ACL MAC address filtering |
|
| Firewall | • Network Address Translation (NAT) • Stateful Packet Inspection (SPI) |
|
| Dimensions | • 164 x 101 x 187 mm (W x D x H) | |
| Weight | • 180 g | |
| Power | • Input: 100 ~ 240 V • Output: 12 V / 1.5A |
|
| Temperature | • Operating: -10°C to 40°C • Storage: -40°C to 70 °C |
|
| Humidity | • Operating: 10% to 95% non-condensing • Storage: 10% to 95% non-condensing |
|
| Certifications | • CE |
Data rates are theoretical. Data transfer rate depends on network capacity, signal strength, and environmental factors. D-Link will provide security updates for the D-Link DWR-M975X until 31st Dec 2026, and extended support may be provided after the stated date and D-Link has the final decision on every security patch adoption and release.
