Technical Specifications
-
Picture/Display
- Panel Size
-
27 inch / 68.6 cm
- Aspect ratio
-
16:9
- LCD panel type
-
IPS technology
- Backlight type
-
Mini LED backlight
- Pixel pitch
-
0.1554 x 0.1554 mm
- Brightness
-
1000 (SDR), 1400 (HDR) cd/m²
- Display colors
-
Color support 1.07 billion colors
- Color gamut (typical)
-
NTSC 121%*, sRGB 154*, Adobe RGB 99.2%*, REC 709 99.1%*, REC 2020 80.4%*
- Color gamut (min.)
-
DCI-P3: 97.2%*
- Contrast ratio (typical)
-
1300:1
- SmartContrast
-
Mega Infinity DCR
- Response time (typical)
-
4 ms (Gray to Gray)*
- Viewing angle
-
-
178º (H) / 178º (V)
-
@ C/R > 10
-
- Picture enhancement
-
SmartImage
- Maximum resolution
-
3840 x 2160 @ 60 Hz
- Effective viewing area
-
596.736 (H) x 335.664 (V)
- Scanning Frequency
-
HDMI/DP: 30 - 140 kHz (H) / 40 - 60 Hz (V); Thunderbolt 4: 30 - 140 kHz (H) / 23 - 75 Hz (V)
- sRGB
-
Yes
- Delta E
-
< 1
- Pixel Density
-
163 PPI
- LowBlue Mode
-
Yes
- Display Screen Coating
-
Anti-Glare, 3H, Haze 25%
- SmartUniformity
-
93 ~ 105%
- EasyRead
-
Yes
- Adaptive sync
-
Yes
- HDR
-
DisplayHDR 1400 certified
-
Connectivity
- Signal Input
-
1 x DisplayPort 1.4, 2 x HDMI 2.0, 1 x Thunderbolt 4 (upstream, data, video, PD 90W)
- Sync Input
-
Separate Sync
- Audio (In/Out)
-
Audio out
- RJ45
-
Ethernet LAN up to 1G*, Wake on LAN
- Signal Output
-
Thunderbolt out: 1 x Thunderbolt 4 (downstream, data, PD 15W)
- HDCP
-
HDMI (HDCP 2.2 / HDCP 1.4), DisplayPort (HDCP 2.2 / HDCP 1.4)
- HBR3
-
Thunderbolt 4
- USB downstream
-
1 x Thunderbolt 4, 4 x USB 3.2 (downstream with 1 fast charge B.C 1.2)*
- USB upstream
-
1 x Thunderbolt 4
-
Power Delivery
- Thunderbolt Power Delivery
-
USB PD version 3.0, 90W (5V/3A, 7V/3A, 9V/3A, 10V/3A, 12V/3A, 15V/3A, 20V/4.5A) + 15W (5V/3A)
-
Convenience
- Built-in Speakers
-
3 W x 2
- Plug & Play Compatibility
-
-
DDC/CI
-
Mac OS X
-
sRGB
-
Windows 10 / 8.1 / 8 / 7
-
- User convenience
-
-
SmartImage
-
Input
-
User
-
Menu
-
Power On/Off
-
- OSD Languages
-
-
Brazil Portuguese
-
Czech
-
Dutch
-
English
-
French
-
Finnish
-
German
-
Greek
-
Hungarian
-
Italian
-
Japanese
-
Korean
-
Portuguese
-
Polish
-
Russian
-
Simplified Chinese
-
Spanish
-
Swedish
-
Traditional Chinese
-
Turkish
-
Ukrainian
-
- Other convenience
-
-
Kensington lock
-
VESA mount (100x100mm)
-
- Control software
-
SmartControl
- MultiView
-
PBP (2x devices)
-
Stand
- Height adjustment
-
130 mm
- Pivot
-
-/+90 degree
- Swivel
-
-/+45 degree
- Tilt
-
-5/15 degree
-
Power
- ECO mode
-
45.1 W (typ.)
- Power supply
-
-
Built-in
-
100-240VAC, 50-60Hz
-
- Off mode
-
Zero watts with Zero switch
- On mode
-
74.5 W (typ.)
- Standby mode
-
0.3 W (typ.)
- Power LED indicator
-
-
Operation - White
-
Standby mode- White (blinking)
-
-
Dimensions
- Packaging in mm (WxHxD)
-
735 x 423 x 285 mm
- Product without stand (mm)
-
613 x 369 x 68 mm
- Packaging in inch (WxHxD)
-
28.9 x 16.7 x 11.2 inch
- Product without stand in inch
-
24.1 x 14.5 x 2.7 inch
- Product with stand(max height)
-
613 x 515 x 204 mm
- Product with stand(max height)
-
24.1 x 20.3 x 8.0 inch
-
Weight
- Product with packaging (kg)
-
14.46 kg
- Product with stand (kg)
-
9.43 kg
- Product with packaging (lb)
-
31.81 lb
- Product with stand (lb)
-
20.75 lb
- Product without stand (kg)
-
7.02 kg
- Product without stand (lb)
-
15.44 lb
-
Operating conditions
- Altitude
-
Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m)
- Temperature range (operation)
-
0°C to 40* °C
- Relative humidity
-
20%-80 %
- Temperature range (storage)
-
-20°C to 60 °C
- MTBF (demonstrated)
-
70,000 hrs (excluded backlight)
-
Sustainability
- Environmental and energy
-
-
PowerSensor
-
LightSensor
-
RoHS
-
- Post consumer recycled plastic
-
35%
- Recyclable packaging material
-
100 %
- Specific Substances
-
-
Mercury free
-
PVC / BFR free housing
-
-
Compliance and standards
- Regulatory Approvals
-
-
CB
-
CE Mark
-
FCC Class B
-
ICES-003
-
cETLus
-
CU-EAC
-
EAEU RoHS
-
TUV Ergo
-
TUV/GS
-
-
Cabinet
- Finish
-
Texture
- Foot
-
Black
- Front bezel
-
Black
- Rear cover
-
Black
-
What's in the box?
- Cables
-
HDMI cable, DisplayPort cable, TBT4 cable, Power cable
- Monitor with stand
-
Yes
- User Documentation
-
Yes
