Appearance
|
| Type |
|
| Dimensions |
Single-sided 42 mm x 22 mm x 2.23 mm (1.65" x 0.87" x 0.09") |
| Weight |
5 g (0.18 oz) |
Interface
|
| Bus Interface |
|
Storage
|
| Flash Type |
|
| Capacity |
- 256 GB/
- 512 GB/
- 1 TB/
- 2 TB
|
Operating Environment
|
| Operating Temperature |
0°C (32°F) ~ 70°C (158°F) |
| Operating Voltage |
|
Performance
|
| Sequential Read/Write (CrystalDiskMark) |
-
2 TB
Up to 2,000/1,700 MB/s
-
1 TB
Up to 2,000/1,700 MB/s
-
512 GB
Up to 2,000/900 MB/s
-
256 GB
Up to 2,000/1,000 MB/s
|
| 4K Random Read/Write (IOmeter) |
-
2 TB
Up to 140,000/250,000 IOPS
-
1 TB
Up to 102,000/275,000 IOPS
-
512 GB
Up to 53,000/235,000 IOPS
-
256 GB
Up to 60,000/240,000 IOPS
|
| Terabytes Written (TBW) |
-
2 TB
800 TBW
-
1 TB
400 TBW
-
512 GB
200 TBW
-
256 GB
100 TBW
|
| Mean Time Between Failures (MTBF) |
2,000,000 hour(s) |
| Drive Writes Per Day (DWPD) |
0.21 (5 yrs) |
| Note |
- Speed may vary due to host hardware, software, usage, and storage capacity.
- The workload used to rate DWPD may be different from your actual workload, which may vary due to host hardware, software, usage, and storage capacity.
- Terabytes Written (TBW) expresses the endurance under the highest capacity.
- Some motherboards only provide PCIe x2 connections for the M.2 slot, creating a bottleneck on even the fastest drives.
|
Warranty
|
| Certificate |
- CE/
- UKCA/
- FCC/
- BSMI/
- KC/
- RCM
|
| Warranty |
- Five-year Limited Warranty
|
| Warranty Policy |
- Please click here for more information about the Transcend Warranty Policy.
- Warranty does not apply when SSD Scope's lifetime indicator displays 0% within the warranty coverage.
|
System Requirement
|
| Operating System |
- Microsoft Windows 7 or later
- Linux Kernel 2.6.31 or later
|
| Note |
- Systems for use with the PCIe M.2 SSD must have an M.2 connector with only an M key. B-key connectors are not compatible. Improper insertion may lead to damage. Please click here for more information.
|
Technology
|
| S.M.A.R.T. |
|
| Advanced Garbage Collection |
|
| RAID Engine |
|
| LDPC Coding |
|
| DRAM Cache |
|
