- New-generation WiFi 6 – Enjoy ultrafast speeds up to 1800 Mbps with the latest WiFi 6 (802.11ax) standard and 80MHz bandwidth for better capacity and efficiency.
- Easy WiFi Portal – Easy share your network with click-through Free WiFi portal; grow your business with sign-on Captive Portal to set up customer or visitor WiFi within steps.
- Ultimate 4G Speed – 4G LTE Category 6 technology lets you enjoy 7X faster speeds than 3G mobile broadband.
- Protection for Your Home Network – lifetime free AiProtection, powered by Trend Micro™, blocks internet security threats for all your connected smart devices.
Model
4G-AX56
Network Standard
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
WiFi 4 (802.11n)
WiFi 5 (802.11ac)
WiFi 6 (802.11ax)
IPv4
IPv6
IEEE 802.11b
IEEE 802.11g
WiFi 4 (802.11n)
WiFi 5 (802.11ac)
WiFi 6 (802.11ax)
IPv4
IPv6
Product Segment
AX1800 ultimate AX performance
WiFi Data Rate
802.11a : up to 54 Mbps
802.11b : up to 11 Mbps
802.11g : up to 54 Mbps
WiFi 6 (802.11ax) (2.4GHz) : up to 574 Mbps
WiFi 6 (802.11ax) (5GHz) : up to 1201 Mbps
802.11b : up to 11 Mbps
802.11g : up to 54 Mbps
WiFi 6 (802.11ax) (2.4GHz) : up to 574 Mbps
WiFi 6 (802.11ax) (5GHz) : up to 1201 Mbps
Connectivity Technology
LTE: Downlink 300 Mbps / Uplink 50 Mbps
HSPA+: Downlink 42 Mbps / Uplink 11 Mbps
4G FDD-LTE: 1 /3 /5 /7 /8 /20 /28
4G TDD-LTE: 38 /40 /41
3G UMTS: 1 /3 /5 /8
HSPA+: Downlink 42 Mbps / Uplink 11 Mbps
4G FDD-LTE: 1 /3 /5 /7 /8 /20 /28
4G TDD-LTE: 38 /40 /41
3G UMTS: 1 /3 /5 /8
Antenna
WiFi: 2 x external fixed antenna
LTE: 1 x external fixed antenna, 1 x internal antenna
LTE: 1 x external fixed antenna, 1 x internal antenna
Memory
128 MB Flash
512 MB RAM
512 MB RAM
Operating Frequency
2.4 GHz / 5 GHz
Operating Mode
Modem Router,Access Point
I/O Ports
1 x Gigabit WAN port, 4 x Gigabit LAN ports, 1 x Nano SIM tray slot
Buttons
Power, Reset, WPS
LED Indicator
Power x 1
WiFi x 2
WAN x 1
Mobile WAN connection x 1
Mobile WAN signal x 3
WiFi x 2
WAN x 1
Mobile WAN connection x 1
Mobile WAN signal x 3
Package Content
4G-AX56
Quick Start Guide
Warranty Card
RJ45 Cable
Power Adapter
Quick Start Guide
Warranty Card
RJ45 Cable
Power Adapter
Product Weight (g)
513
Product Dimensions
242 x 100 x 325
Parental Control
"Allow you to block access to unwanted websites and apps."
Customized Internet Schedule
Customized Internet Schedule
Guest Network
Support Guest Network
Guest Network Connection Time Limit
Guest Network Connection Time Limit
Security
WPA/WAP2-Enterprise,WPA/WPA2-Personal,WPA2-Enterprise,WPA2-Personal,WPA2/WPA3-Personal,WPA3-Persona
WPS
SSH
Firewall
64
32
WPS
SSH
Firewall
64
32
AiProtection
AiProtection Classic
• Router Security Assessment
• Malicious Site Blocking
• Router Security Assessment
• Malicious Site Blocking
VPN
VPN Client L2TP
VPN Client Open VPN
VPN Client PPTP
VPN Server Open VPN
VPN Server PPTP
VPN Client Open VPN
VPN Client PPTP
VPN Server Open VPN
VPN Server PPTP
Traffic Control
• Bandwidth Limiter
Traditional QoS
Real-time traffic monitor
Wired Traffic Monitor
Traditional QoS
Real-time traffic monitor
Wired Traffic Monitor
WAN
Internet Connection Type : Mobile WAN, Ethernet WAN
Dual WAN
Port Forwarding
DMZ
DDNS
NAT Passthrough : PPTP, L2TP, IPSec, RTSP, H.323, SIP Passthrough, PPPoE relay
Dual WAN
Port Forwarding
DMZ
DDNS
NAT Passthrough : PPTP, L2TP, IPSec, RTSP, H.323, SIP Passthrough, PPPoE relay
LAN
DHCP Server
IGMP Snooping
IPTV
Manually Assign IP Address
Maximum Manually Assign IP Address Rule : 64
Wake on LAN (WOL)
IGMP Snooping
IPTV
Manually Assign IP Address
Maximum Manually Assign IP Address Rule : 64
Wake on LAN (WOL)
Wireless
MU-MIMO
UTF-8 SSID
WiFi MAC Address Filter
Wireless Scheduler
Airtime Fairness
Universal Beamforming
Explicit Beamforming
UTF-8 SSID
WiFi MAC Address Filter
Wireless Scheduler
Airtime Fairness
Universal Beamforming
Explicit Beamforming
User Interface
WEB: ASUSWRT
APP: ASUS Router APP
APP: ASUS Router APP
Administration
SMS Message
Configuration Backup and Restore
Diagnosis Tools
Feedback System
System Log
Configuration Backup and Restore
Diagnosis Tools
Feedback System
System Log
