Hardware Specifications |
||
---|---|---|
CPU Model | Intel Celeron N5105 | |
CPU Architecture | x64 64-bit | |
CPU Frequency | Quad-Core 2.0GHz (burst up 2.90 GHz) | |
Memory | 4GB SO-DIMM DDR4 Compatibility | |
Memory Module Pre-installed | 4GB (1x 4GB) | |
Total Memory Slots | 2 | |
Memory Expandable up to | 16GB (2x 8GB) Installation Guide
|
|
Flash Memory | 8GB eMMC | |
Drive Bays | 2 | |
M.2 Drive Slots | 4 Installation Guide | |
Compatible Drive Type Compatibility |
|
|
Maximum Drive Bays with Expansion Unit | 10 | |
Supports Hot Swappable Drives | ||
Expansion | 2x USB 3.2 Gen 2 (10Gbps) | |
Network | 2x 2.5 Gigabit Ethernet (2.5G/1G/100M) | |
Multimedia Output | 1x HDMI 2.0b | |
System Fan | 1x 70mm | |
Infrared Receiver | ||
Power Supply Unit / Adapter | 65W x1 | |
Input Power Voltage | 100V to 240V AC | |
Certification | FCC, CE, VCCI, BSMI, C-TICK, KCC, BIS, CCC, UKCA | |
Warranty | 3 Years | |
Power Consumption | 21 W (Operation); 13.5 W (Disk Hibernation); 0.79 W (Sleep Mode) |
|
Noise Level | 17.7dB (HDD idle) | |
Operation Temperature | 0°C~40°C (32°F~104°F) | |
Storage Temperature | -20°C~70°C (-4°F~158°F) | |
Humidity | 5% to 95% RH | |
Size | 163.5 (H) x 108 (W) x 230 (D) mm | |
Weight | 2 kg / 4.4 lb Package Contents |
Software & Features |
||
---|---|---|
Supported OS |
|
|
Supported Languages | Deutsch, English, Français, Italiano, Nederlands, Русский, 日本語, 한글, 简体中文, 繁體中文, Česká, Polski, Svenska, Dansk, Norsk, Suomi, Português, Türkçe, Español, Magyar, ภาษาไทย | |
Supported Browsers |
|
|
Network Protocols | CIFS / SMB, SMB 2.0 / 3.0, AFP, NFS, FTP (Unicode Supported), TFTP, WebDAV, Rsync, SSH, SFTP, iSCSI/IP-SAN, HTTP, HTTPS, Proxy, SNMP, Syslog | |
Connection and transmission |
|
|
File System |
|
|
File Explorer |
|
|
Network Recycle Bin |
|
|
Supported RAID levels |
|
|
Supported RAID migration methods |
|
|
RAID levels supporting storage expansion by complete drive replacement |
|
|
RAID levels supporting storage expansion by drive addition | - | |
RAID spare drive support | - | |
Supported RAID levels |
|
|
Supported RAID migration methods |
|
|
RAID levels supporting storage expansion by complete drive replacement |
|
|
RAID levels supporting storage expansion by drive addition |
|
|
Supported RAID migration methods |
|
|
MyArchive |
|
|
iSCSI/IP-SAN |
|
|
Disk Management |
|
|
Access Control |
|
|
ACL |
|
|
SSD Cache |
|
|
System Administration |
|
|
Security |
|
|
Network Defender |
|
|
Backup Solutions |
|
|
Snapshots |
|
|
ASUSTOR Hightlight |
|
|
Eco-Friendly Design |
|
|
Energy Control |
|
