ASUSTOR NIMBUSTOR 2 Gen2 (AS5402T)
ASUSTOR NIMBUSTOR 2 Gen2 (AS5402T)
ASUSTOR NIMBUSTOR 2 Gen2 (AS5402T)
ASUSTOR NIMBUSTOR 2 Gen2 (AS5402T)
1/ 2
Home / ASUSTOR NIMBUSTOR 2 Gen2 (AS5402T)

ASUSTOR NIMBUSTOR 2 Gen2 (AS5402T)

Warranty - 3 years
$649.00 SGD
$0.00 SGD
(tax included)
Quantity
Only 1 left
Volume Pricing
Quantity
Price
1+
$649.00 SGD each
Local Shipping
Local Warranty
Secure Payment
Please Whatsapp +65 85004522 first for stock availability before making payment and checkout

Hardware Specifications
CPU Model Intel Celeron N5105
CPU Architecture x64 64-bit
CPU Frequency Quad-Core 2.0GHz (burst up 2.90 GHz)
Memory 4GB SO-DIMM DDR4 Compatibility
Memory Module Pre-installed 4GB (1x 4GB)
Total Memory Slots 2
Memory Expandable up to 16GB (2x 8GB) Installation Guide
  • Support mixed capacity
Flash Memory 8GB eMMC
Drive Bays 2
M.2 Drive Slots 4 Installation Guide
Compatible Drive Type Compatibility
  • 3.5" SATA HDD
  • 2.5" SATA HDD
  • 2.5" SATA SSD
  • M.2 2280 NVMe
Maximum Drive Bays with Expansion Unit 14
Supports Hot Swappable Drives
Expansion 3x USB 3.2 Gen 2 (10Gbps)
Network 2x 2.5 Gigabit Ethernet (2.5G/1G/100M)
Multimedia Output 1x HDMI 2.0b
System Fan 1x 70mm
Infrared Receiver
Power Supply Unit / Adapter 65W x1
Input Power Voltage 100V to 240V AC
Certification FCC, CE, VCCI, BSMI, C-TICK, KCC, BIS, CCC, UKCA
Warranty 3 Years
Power Consumption 22.9 W (Operation);
12.7 W (Disk Hibernation);
0.71 W (Sleep Mode)
Noise Level 18.6dB (HDD idle)
Operation Temperature 0°C~40°C (32°F~104°F)
Storage Temperature -20°C~70°C (-4°F~158°F)
Humidity 5% to 95% RH
Size 170 (H) x 114 (W) x 230 (D) mm
Weight 1.71 kg / 3.77 lb Package Contents



Software & Features
Supported OS
  • Windows 7, 8, 10, 11, Server 2008, Server 2012, Server 2016, Server 2019, Server 2022
  • macOS
  • UNIX, Linux, and BSD
Supported Languages Deutsch, English, Français, Italiano, Nederlands, Русский, 日本語, 한글, 简体中文, 繁體中文, Česká, Polski, Svenska, Dansk, Norsk, Suomi, Português, Türkçe, Español, Magyar, ภาษาไทย
Supported Browsers
  • Firefox
  • Chrome
  • Safari
  • Microsoft Edge
Network Protocols CIFS / SMB, SMB 2.0 / 3.0, AFP, NFS, FTP (Unicode Supported), TFTP, WebDAV, Rsync, SSH, SFTP, iSCSI/IP-SAN, HTTP, HTTPS, Proxy, SNMP, Syslog
Connection and transmission
  • TCP/IP (IPv4 & IPv6)
  • Link Aggregation: Supports 802.3ad and Six Other Modes for Load Balancing and/or Network Failover
  • Jumbo Frame (MTU)
  • VLAN
  • EZ Connect
  • Wireless Network
  • DDNS and EZ-RouterCompatibility
  • Supports Wake-on-LAN (WOL)  See More
  • Supports Wake-on-WAN (WOW)  See More
File System
  • Internal Disk: EXT4 ,Btrfs
  • External Disk: FAT32, NTFS, EXT3, EXT4, HFS+, exFAT ,Btrfs
File Explorer
  • Web-based File Management
  • ISO File Mounting
  • Share Links
  • Task Monitor
  • Browse Files on Local PC
  • Thumbnail Previews
  • Data Access via External Optical Drive
  • Supports video playback
Network Recycle Bin
  • Share folder-based
  • Maintains original directory structure and file permission
  • On-click restore
  • Supports scheduled emptying
  • Filtering rules
    1. File size
    2. File extension
  • Deletion Settings
    1. File size
    2. File date
Supported RAID levels
  • Single
  • JBOD
  • RAID 0
  • RAID 1
Supported RAID migration methods
  • Single to RAID 1
RAID levels supporting storage expansion by complete drive replacement
  • RAID 1
RAID levels supporting storage expansion by drive addition -
RAID spare drive support -
Supported RAID levels
  • Single
  • JBOD
  • RAID 0
  • RAID 1
  • RAID 5
  • RAID 6
  • RAID 10
Supported RAID migration methods
  • Single to RAID 1
  • Single to RAID 5
  • Single to RAID 6
  • Single to RAID 10
  • RAID 1 to RAID 5
  • RAID 1 to RAID 6
  • RAID 1 to RAID 10
  • RAID 5 to RAID 6
RAID levels supporting storage expansion by complete drive replacement
  • RAID 1
  • RAID 5
  • RAID 6
  • RAID 10
RAID levels supporting storage expansion by drive addition
  • RAID 5
Supported RAID migration methods
  • RAID 1
  • RAID 5
MyArchive
  • Hot swappable design enables easy transfer or exchange of high amounts of data
  • Works on any empty bay on an ASUSTOR NAS
  • File system support: EXT4, NTFS, HFS+, Btrfs and exFAT
  • Supports AES 256-bit encryption on EXT4 and Btrfs
  • Supports Btrfs snapshots
  • Supports decryption with a USB key
iSCSI/IP-SAN
  • Maximum Targets: 256
  • Maximum LUNs: 256
  • Maximum Snapshot Versions of a Single LUN: 256
  • Target Masking
  • LUN Mapping
  • ISO File Mounting
  • Supports MPIO
  • Persistent (SCSI-3) Reservations
Disk Management
  • Scheduled Bad Block Scans
  • Scheduled S.M.A.R.T Scans
Access Control
  • Maximum Number of Users: 4096
  • Maximum Number of Groups: 512
  • Maximum Number of Shared Folders: 512
  • Maximum Number of Concurrent Connections: 512
  • Supports Windows Active Directory
  • Supports Windows Active Directory / LDAP
ACL
  • Provides both Windows ACL and Linux ACL permission configuration methods
  • Can enable Windows ACL for specific shared folders
  • Comprehensive support for Windows’ 13 types of advanced permission settings
  • Can view Windows ACL permission settings from within ADM
  • Supports local users and groups
  • Exclusive permission reset function allows users to quickly restore default permissions
SSD Cache
  • SSD-like performance with traditional hard drives
  • Supports read-only access and read-write cache mode
System Administration
  • Log Type: System Log, Connection Log, File Access Log
  • Real-time Online User Monitor
  • Real-time System Monitor
  • User Quota
  • Virtual Drive (ISO Mounting, Maximum 16)
  • UPS SupportCompatibility
Security
  • AES 256-Bit Encryption
  • Firewall: Prevent Unauthorized Access
  • Alert Notifications: E-mail, SMS
  • Encrypted Connections: HTTPS, FTP over SSL/TLS, SSH, SFTP, Rsync over SSH
  • Built-in Hardware Encryption Engine
Network Defender
  • Auto black list
  • Trusted list
  • Black/White list
    • Supports IP/IP range/geolocation
Backup Solutions
  • Rsync (Remote Sync) Backup
  • Cloud Backup
  • FTP Backup
  • External Backup
  • One Touch Backup
  • EZ Sync
  • SMB Backup
Snapshots
  • Btrfs Snapshots
  • 256 Snapshots
  • iSCSI LUNs
ASUSTOR Hightlight
  • System Migration
  • EZ Connect
  • Dr. ASUSTOR
  • 2-way Backup
  • Task Monitor
Eco-Friendly Design
  • System Automatically Enters Sleep Mode (Schedule S3)
  • Auto-Standby for Both Internal and External Disks
  • Auto Fan Control
  • LED Night Mode
  • Power Schedule: On, Off, Restart, and Sleep
Energy Control
  • Configurable Disk Hibernation and Sleep Mode Wait Time
  • Configurable Time Period for Sleep Mode Activation
  • Automatic Sleep
