Model NumberMB540-KGNN-S00
Color(s)Black
Materials - ExteriorSteel, Mesh, Plastic
Materials - Left Side PanelTempered Glass
Dimensions (L x W x H)499.3 x 208.6 x 498mm (incl. Protrusions), 488.3 x 208.6 x 498mm (excl. Protrusions)
Volume51.87L (exlc. Protrusions)
Motherboard SupportMini-ITX, Micro-ATX, ATX, E-ATX* (*up to 12" x 10.7" motherboards, may impact cable management feature)
Expansion Slots7
5.25" Drive Bays0
2.5" / 3.5" Drive Bays (Combo)2
2.5" Drive Bays4
I/O Panel - USB Ports1x USB 3.2 Gen 1 Type A, 1x USB 3.2 Gen 2 Type C
I/O Panel - Audio In / Out1x 3.5mm Headset Jack (Audio+Mic)
I/O Panel - Other1x Reset/ARGB button
Pre-installed Fans - TopN/A
Pre-installed Fans - FrontN/A
Pre-installed Fans - Rear1x 120mm 650~1800RPM SickleFlow PWM ARGB
Fan Support - Top3x 120mm / 2x 140mm
Fan Support - Front3x 120mm / 2x 140mm
Fan Support - Rear1x 120mm
Radiator Support - Top120 / 140 / 240 / 280 / 360mm (recommended maximum thickness - 55mm)
Radiator Support - Front120 / 140 / 240 / 280 / 360mm
Radiator Support - Rear120mm
Clearance - CPU Cooler165mm/6.49"
Clearance - PSU180mm / 7.08" (295mm / 11.61" with HDD cage removed)
Clearance - GFX410mm/16.1"
Dust FiltersFront, Top, Bottom
Power Supply SupportATX
Warranty2 years
SizeMid Tower
SeriesMasterBox Series
