MaterialsSteel
Radiator Support - Rear120mm
Power Supply SupportBottom Mount
Dust FiltersTop
5.25" Drive BaysN/A
Clearance - PSU140mm (HDD cage in backmost position)
Dust FiltersFront
Warranty2 years
3.5" Drive Bays2
MaterialsPlastic
Color(s)Black
SeriesMasterBox Series
SizeMini Tower
2.5" Drive Bays2
MaterialsTempered Glass
Dust FiltersBottom
Power Supply SupportATX
Fan Support - Rear1x 120mm
Radiator Support - Front280mm
Radiator Support - Front240mm
Radiator Support - Top240mm
Fan Support - Top2x 120/140mm
Radiator Support - Front140mm
Motherboard SupportMicro ATX
Radiator Support - Top120mm
Radiator Support - Front120mm
Cable Routing18-22mm
ARGB ControllerMasterBox MB320L ARGB: 1x ARGB 1-to-3 Splitter, MasterBox MB320L ARGB with Hub: 1x ARGB Hub
Clearance - PSU325mm (w/o front radiator & HDD cage)
Expansion Slots4
Clearance - CPU Cooler166mm/6.54"
Motherboard SupportMini ITX
Weight5.47kg
Fan Support - Front3 x 120mm* / 2 x 140mm
Fan Support - Front*can only mount behind the front plate
Clearance - GFX344mm
Pre-installed Fans - Front2x 120mm CF120 ARGB Fan
I/O Panel2x USB 3.2 Gen 1 (USB 3.0), 1x 3.5mm Audio Jack, 1x 3.5mm Mic Jack
Dimensions (L x W x H)435.5 x 217.5 x 410mm
Model NumberMasterBox MB320L ARGB: MCB-B320L-KGNN-S01, MasterBox MB320L ARGB with Hub: MCB-B320L-KGNN-S02
