Fixed Network Broadband Router
• Supports WAN connection types: DHCP,Static IP, PPPoE
• Supports DDNS and DHCP Servers
Mobile network
• Supports 3G and LTE technology
• Supports auto and manual APN settings
• Supports LTE to ETH WAN Fail-Over
Secure Network Connection
• Supports Wi-Fi Protected Setup (WPS)
• Support WEP/WPA/WPA2/WPA3 wireless security encryption
• Supports NAT firewall, IP / URL-based access control and MAC address filtering
Specifications
| Frequency Support | • FDD LTE: B1/3/5/7/8/20/28 • TDD 38,40,41 • WCDMA:B1/5/8 |
|
| Device Interfaces | • 1x Gigabit Ethernet WAN/LAN port 1 • 3x Gigabit Ethernet LAN ports • 1x Reset/WPS button • 1x Power Jack • 2 x 5dBi external LTE antennas • 2 x 5dBi external WiFi antennas • 1x Power switch • 1x LTE Interface • 1x Nano SIM card slot |
|
| Data Rate | • 2.4GHz & 5GHz up to 1500Mbps | |
| Standards | • 802.11b/g/n/ac/ax | |
| Wi-Fi Data Rate | • 2.4GHz (20/40MHz): up to 300 Mbps • 5GHz (20/40/80MHz): up to 1204 Mbps |
|
| Dimensions | • 164 x 101 x 187mm (W x D x H0 | |
| Weight | • 180g | |
| Power | • Input: 100 ~ 240V • 12V / 1.5A |
|
| Temperature | • Operating : -10°C to 40°C • Storage: -40°C to 70°C |
|
| Humidity | • Operating : 10% to 95% non-condensing • Storage : 10% to 95% non condensing |
|
| Certifications | • CE |
