Compatibility |
Intel LGA1700/1200/1151/1150/1155/1156 AMD AM5/AM4 |
TDP |
220W |
Overall Dimension |
120×75×151mm (L×W×H) |
Heatsink Material |
4×Ф6mm Heatpipe (Direct Touch) + Aluminum Fin |
Weight |
650g (heatsink+fan) |
Fan Dimension |
120×120×25mm |
Fan Speed |
600±200 ~ 1500±10% RPM |
Max. Air Flow |
70CFM |
Max. Static Pressure |
2.15mmH2O |
Noise |
28.9dB(A) Max. |
Rated Voltage |
12VDC (4pin PWM) |
Operating Voltage |
10.8 ~ 13.2VDC |
Started Voltage |
7VDC |
Rated Current |
0.2A |
Power Input |
2.4W |
Bearing Type |
Hydraulic |
Connector |
4Pin PWM |
EAN |
6931393304564 |
