SPECIFICATIONS
| MODEL NAME | A3-mATX | |||
|---|---|---|---|---|
|
MODEL N O. |
A3-mATX BLACK | A3-mATX WHITE | A3-mATX-WD BLACK | A3-mATX-WD WHITE |
| COLOR | Black | White | Black (Wood Edition) | White(Wood Edition) |
| CASE TYPE | MFF (Micro Form Factor) | |||
| DIMENSION | (D) 443mm x (W) 194mm x (H) 321.5mm (D) 443mm x (W) 194mm x (H) 306mm(w/o feet) |
|||
| CAPACITY | 26.3L | |||
| MATERIAL | Steel | |||
| MOTHERBOARD SUPPORT | M-ATX/ITX | |||
| PSU SUPPORT | ATX/SFX/SFX-L (Max 220mm) | |||
| FAN SUPPORT | Top: 3 x 120mm Side: 3 x 120mm or 2 x 140mm Bottom: 3 x 120mm Rear: 1 x 120mm |
|||
| RADIATOR SUPPORT | Top: 1 x 360/240mm Side: 1 x 360/280/240mm Bottom: 1 x 240mm (360mm with fan at the bottom) |
|||
| DRIVE SUPPORT | Tray: 2 × 2.5” SSD Bottom: 1 × 2.5” SSD or 1 × 3.5” HDD |
|||
| GPU LENGTH CLEARANCE | Max 415mm | |||
| CPU HEIGHT CLEARANCE | Max 165mm | |||
| EXPANSION SLOTS | 4 | |||
| I/O PORTS | 1 x Power Button 2 x USB 3.0 TYPE-A 1 x USB 3.1 TYPE-C 1 x Mic 1 x HD Audio | |||
| DUST FILTER | 1 x Bottom | 1 x Bottom 1 x Front |
||
| WARRANTY | 1 year | |||
