- 4G network – Enjoy the 4G LTE download speeds up to 150 Mbps.
- Plug a SIM card and play – No configurations needed, compatibility of SIM cards are assured by years of field tests
- 300 Mbps WiFi – Fast WiFi speeds up to 300 Mbps to share your network
- Simultaneous Connection– Share internet access with up to 32 Wi-Fi devices
- Wi-Fi router mode – Plug an Ethernet cable into the LAN/WAN port for flexible access if you can't get a 4G connection
- Wireless
- Wireless Standards
-
IEEE 802.11b/g/n
- Frequency
-
2.4 GHz
- WiFi Speeds
-
300 Mbps
- Reception Sensitivity
-
11g 54M: -74 dBm
11n HT20: -71 dBm
11n HT40: -68 dBm - Transmission Power
-
< 20 dBm (2.4 GHz)
- Wireless Security
-
WPA-PSK / WPA2-PSK
- Wireless Functions
-
Enable/Disable Wireless Radio, Wireless Schedule, WMM, Wireless
Statistics
- Software
- DHCP
-
Server
- Hardware
- Dimensions
-
95×61.05×165.97 mm
- Interfaces
-
1× 10/100Mbps LAN/WAN Port
1× 10/100Mbps LAN Port
1× Nano SIM Card Slot
- Button
-
WPS/Reset Button
- Ethernet Ports
-
1× 10/100 Mbps LAN/WAN Port +
1× 10/100 Mbps LAN
- Network Type
-
EU:
FDD-LTE: B1/B3/B5/B7/B8/B20/B28 (2100/1800/850/2600/900/800/700 MHz)
TDD-LTE: B38/B40 (2600/2300 MHz)
HSPA+/UMTS: B1/B5/B8 (2100/850/900 MHz)
- Others
- Package Contents
-
300 Mbps Wireless N 4G LTE Router (MB112-4G)
Power Adapter
RJ45 Ethernet Cable
Quick Installation Guide
- Environment
-
Operating Temperature: 0°C~40°C (32°F~104°F)
Storage Temperature: -40°C~60°C (-40°F~140°F)
Operating Humidity: 10%~90% Non-Condensing
Storage Humidity: 5%~90% Non-Condensing
