Technical Specifications
-
Connectivity
- Signal Input
-
DisplayPort 1.4 x 1, HDM 1.4 x 2, USB-C 3.2 Gen 2 x 1 (upstream, power delivery up to 90 W)
- Sync Input
-
Separate Sync
- Audio (In/Out)
-
Audio out
- RJ45
-
Ethernet LAN up to 1 G*, Wake on LAN
- Signal Output
-
DisplayPort out
- USB:
-
USB-C x 1 (upstream), USB 3.2 x 4 (downstream with 1 fast charge B.C 1.2)
- HDCP
-
HDCP 1.4 (HDMI/DP/USB-C)
- HBR3
-
for USB-C
-
Picture/Display
- Panel Size
-
27 inch/68.6 cm
- Aspect ratio
-
16:9
- LCD panel type
-
IPS technology
- Backlight type
-
W-LED system
- Pixel pitch
-
0.2331 x 0.2331 mm
- Brightness
-
350 cd/m²
- Display colours
-
16.7 M
- Colour gamut (typical)
-
NTSC 104%*, sRGB 107%*
- Contrast ratio (typical)
-
1000:1
- SmartContrast
-
50,000,000:1
- Response time (typical)
-
c4 ms (Grey to Grey)*
- Viewing angle
-
-
178º (H)/178º (V)
-
@ C/R > 10
-
- Picture enhancement
-
SmartImage
- Maximum resolution
-
2560 x 1440 @ 75 Hz*
- Effective viewing area
-
596.736 (H) x 335.664 (V)
- Scanning Frequency
-
30–114 kHz (H)/48–75 Hz (V)
- sRGB
-
Yes
- Flicker-free
-
Yes
- Pixel Density
-
109 PPI
- LowBlue Mode
-
Yes
- Display Screen Coating
-
Anti-Glare, 3H, Haze 25%
- EasyRead
-
Yes
-
USB
- Power delivery
-
USB PD version 3.0
- Super speed
-
Data and Video transfer
- DP
-
Built-in Display Port Alt mode
- USB-C max. power delivery
-
Up to 90 W (5 V/3 A; 7 V/3 A; 9 V/3 A; 10 V/3 A; 12 V/3 A; 15 V/3 A; 20 V/4.5 A)
- USB-C
-
Reversible plug connector
-
Convenience
- Built-in Speakers
-
2 W x 2
- Plug and Play Compatibility
-
-
DDC/CI
-
Mac OS X
-
sRGB
-
Windows 10 / 8.1 / 8 / 7
-
- User convenience
-
-
SmartImage
-
Input
-
PowerSensor
-
Menu
-
Power On/Off
-
- OSD Languages
-
-
Brazil Portuguese
-
Czech
-
Dutch
-
English
-
French
-
Finnish
-
German
-
Greek
-
Hungarian
-
Italian
-
Japanese
-
Korean
-
Portuguese
-
Polish
-
Russian
-
Simplified Chinese
-
Spanish
-
Swedish
-
Traditional Chinese
-
Turkish
-
Ukrainian
-
- Other convenience
-
-
Kensington lock
-
VESA mount (100 x 100 mm)
-
- Control software
-
SmartControl
-
Stand
- Height adjustment
-
150 mm
- Pivot
-
-90/+90
- Swivel
-
-180/+180 degree
- Tilt
-
-5/35 degree
-
Power
- ECO mode
-
16.4 W (typ.)
- Power supply
-
-
Built-in
-
100–240 VAC, 50–60 Hz
-
- Off mode
-
Zero watts with Zero switch
- On mode
-
20.2 W (typ.) (EnergyStar test method)
- Standby mode
-
0.3 W
- Power LED indicator
-
-
Operation - White
-
Standby mode - White (flashing)
-
- Energy Label Class
-
E
-
Dimensions
- Packaging in mm (W x H x D)
-
730 x 471 x 193 mm
- Product without stand (mm)
-
613 x 366 x 54 mm
- Product with stand (max height)
-
613 x 537 x 225 mm
-
Weight
- Product with packaging (kg)
-
10.94 kg
- Product with stand (kg)
-
7.26 kg
- Product without stand (kg)
-
5.47 kg
-
Operating conditions
- Altitude
-
Operation: +12,000 ft (3658 m), Non-operation: +40,000 ft (12,192 m)
- Temperature range (operation)
-
0°C to 40°C °C
- Relative humidity
-
20%-80 %
- Temperature range (storage)
-
-20°C to 60°C °C
- MTBF (demonstrated)
-
70,000 hrs (excluded backlight)
-
Sustainability
- Environmental and energy
-
-
PowerSensor
-
LightSensor
-
EnergyStar 8.0
-
EPEAT*
-
TCO Certified Edge
-
RoHS
-
- Post-consumer recycled plastic
-
85%
- Recyclable packaging material
-
100 %
- Specific Substances
-
-
Mercury free
-
PVC/BFR free housing
-
-
Compliance and standards
- Regulatory Approvals
-
-
cETLus
-
CB
-
TUV/GS
-
TUV Ergo
-
SEMKO
-
CU-EAC
-
EAEU RoHS
-
CE Mark
-
FCC Class B
-
ICES-003
-
UKRAINIAN
-
TUV Eye Comfort certified
-
CCC
-
CECP
-
CEL
-
-
Cabinet
- Finish
-
Texture
- Foot
-
Black
- Front bezel
-
Black
- Rear cover
-
Black
-
What's in the box?
- Cables
-
HDMI cable, DP cable, USB-C to C/A Y cable, Power cable
- Monitor with stand
-
Yes
- User Documentation
-
Yes
