Technical Specifications
-
Picture/Display
- Panel Size
-
19 inch / 48.3 cm
- Aspect ratio
-
5:4
- LCD panel type
-
IPS-ADS LCD
- Backlight type
-
W-LED system
- Pixel pitch
-
0.293 x 0.293 mm
- Optimum resolution
-
1280 x 1024 @ 60Hz
- Brightness
-
250 cd/m²
- Display colors
-
16.7 M
- Contrast ratio (typical)
-
1,000:1
- SmartContrast
-
20,000,000:1
- Response time (typical)
-
5 ms (Gray to Gray)*
- Viewing angle
-
-
178º (H) / 178º (V)
-
@ C/R > 10
-
- Picture enhancement
-
SmartImage
- Effective viewing area
-
374.78 x 299.83 mm
- Scanning Frequency
-
30 -83 kHz (H) / 56 -76 Hz (V)
- sRGB
-
Yes
- Display Screen Coating
-
Anti-Glare, 3H, Haze 25%
-
Connectivity
- Signal Input
-
-
DVI-D (digital, HDCP)
-
VGA (Analog )
-
- Sync Input
-
-
Separate Sync
-
Sync on Green
-
- Audio (In/Out)
-
-
PC audio-in
-
Headphone out
-
-
Convenience
- Built-in Speakers
-
1.5W x 2
- Plug & Play Compatibility
-
-
DDC/CI
-
Mac OS X
-
sRGB
-
Windows 8.1 / 8 / 7
-
- User convenience
-
-
SmartImage
-
Volume
-
SmartPower
-
Menu
-
Power On/Off
-
- OSD Languages
-
-
Brazil Portuguese
-
Czech
-
Dutch
-
English
-
Finnish
-
French
-
German
-
Greek
-
Hungarian
-
Italian
-
Japanese
-
Korean
-
Polish
-
Portuguese
-
Russian
-
Simplified Chinese
-
Spanish
-
Swedish
-
Traditional Chinese
-
Turkish
-
Ukrainian
-
- Other convenience
-
-
Kensington lock
-
VESA mount (100x100mm)
-
- Control software
-
SmartControl Premium
-
Stand
- Tilt
-
-5/20 degree
-
Power
- ECO mode
-
8 W (typ.)
- Power supply
-
-
Built-in
-
100-240VAC, 50-60Hz
-
- Off mode
-
<0.3 W (typ.)
- On mode
-
11.13 W (typ.) (EnergyStar test method)
- Standby mode
-
<0.3 W (typ.)
- Power LED indicator
-
-
Operation - White
-
Standby mode- White (blinking)
-
-
Dimensions
- Product with stand (mm)
-
404 x 418 x 194 mm
- Packaging in mm (WxHxD)
-
465 x 457 x 139 mm
- Product without stand (mm)
-
404 x 346 x 61 mm
-
Weight
- Product with packaging (kg)
-
4.82 kg
- Product with stand (kg)
-
3.20 kg
- Product without stand (kg)
-
2.80 kg
-
Operating conditions
- Temperature range (operation)
-
0°C to 40 °C
- Relative humidity
-
20%-80 %
- Temperature range (storage)
-
-20°C to 60 °C
- MTBF (demonstrated)
-
70,000 hrs (excluded backlight)
-
Sustainability
- Environmental and energy
-
-
EnergyStar 8.0
-
EPEAT*
-
TCO Certified
-
RoHS
-
- Recyclable packaging material
-
100 %
- Specific Substances
-
-
PVC / BFR free housing
-
Mercury free
-
- Recycled material
-
25%
-
Compliance and standards
- Regulatory Approvals
-
-
CE Mark
-
FCC Class B
-
BSMI
-
GS
-
ERGO
-
WEEE
-
PSB
-
C-Tick
-
cETLus
-
TUV Ergo
-
TUV/GS
-
UKRAINIAN
-
CCC
-
CECP
-
-
Cabinet
- Finish
-
Texture
- Foot
-
Black
- Front bezel
-
Black
- Rear cover
-
Black
