| Razer Core X V2 Approx. Dimensions |
|
|---|---|
| Weight (approximate) |
3.9 kg / 8.64 lbs
|
| Connection to PC |
Thunderbolt™ (USB-C) using included Thunderbolt™ 5 cable
|
| Compatible Laptops |
Laptops and other devices require a Thunderbolt™ 4, Thunderbolt™ 5 or USB 4 port with external graphics support.
Please check with your laptop or device manufacture to confirm if your laptop supports external graphics. |
| Razer Core X V2 Max Inner Dimensions |
|
| System Requirements |
Windows® 11 OS and Thunderbolt™ 4, Thunderbolt™ 5 or USB 4 port and eGPU compatibility
See following graphics card compatibility list for compatible devices. |
| GPU Support (Graphics Card Not Included) |
GPU Type:
Supports up to 4-Slot wide, full-length, PCI-Express x16 graphics card. Graphics card (GPU) sold separately Windows 11 compatible graphics chipsets: Graphics cards use varied designs based around a common graphics chip. Please ensure the GPU selected meets all size, power, and additional requirements. Qualified NVIDIA® GeForce® graphics chipsets Qualified AMD Radeon™ graphics chipsets Graphics Output: Based on capabilities of installed graphics |
| Expansion Slot |
PCIe 4.0 x 4
|
| Input & Output |
Thunderbolt™ (USB C) for connection to compatible Thunderbolt™ 5, Thunderbolt™ 4 or USB 4 device
|
| Internal Power Supply |
Desktop ATX Power Supply sold separately
|
| Laptop Power Delivery |
Up to 140 Watts via USB-C
|
| Included Cables |
Thunderbolt™ 5 cable
|
| Thunderbolt™ Cable Length |
1 m
|
